LG-Ericsson iPECS-MG - Wireless DECT Terminal; Mpb Voip; VOIP Channels (VOIB); Other System Specifications

iPECS-MG Hardware Description and Installation Manual Issue 1.1
System Overview August, 2010
9
2.4.8 Wireless DECT Terminal
ITEM SPECIFICATION
Max. Transmission Power 250 mW
Modulation Method GFSK
Frequency Band 1,880MHz ~ 1,900MHz
2.4.9 MPB VOIP
ITEM SPECIFICATION
LAN Interface 10 / 100 Base-T Ethernet (IEEE 802.3)
Speed 10 Mbps or 100 Mbps (Auto-Negotiation)
Duplex Half Duplex or Full Duplex (Auto-Negotiation)
VoIP Protocol SIP (RFC3261) and H.323 Revision 2
Voice Compression G.711/G.729A/G.723.1
Voice/Fax Switching T.38
Echo cancellation G.168
2.4.10 VOIP channels (VOIB)
ITEM SPECIFICATION
LAN Interface 10 / 100 Base-T Ethernet (IEEE 802.3)
Speed 10 Mbps or 100 Mbps (Auto-Negotiation)
Duplex Half Duplex or Full Duplex (Auto-Negotiation)
VoIP Protocol SIP (RFC3261) and H.323 Revision 2
Voice Compression G.711/G.729/G.723.1
Voice/Fax Switching T.38
Echo cancellation G.168
2.4.11 Other System Specifications
ITEM DESCRIPTION SPECIFICATION
CPU M82805G, ARM9 Dual core (32bit, 375MHz)
Switching Device ACT2, Custom Mixed-Signal ASIC Device
Memory Back-up Duration 7 years
Ring Signal 70Vrms, 25Hz
External Relay Contact 1A @30Volt DC
External Music Port 0dBm @600ohm
External Paging Port 0dBm @600ohm
Analog Modem Bell, ITU-T, V.34 V.32BIS, V.90
Speed 300bps up to 33Kbps speed rate
MODU
Connection Automatic rate negotiation
Version USB 1.1 compliant
Speed Max. 12Mbps
USB
Mode Host Mode (Memory stick) only
