iPECS-MG Hardware Description and Installation Manual Issue 1.1
DECT INSTALLATION August, 2010
38
Figure 5.3.2.3-1 ISDN Connections (Basic Rate)
5.3.2.4 Serial Port
The PRIB includes an Audio jack connected to a Serial port. The serial port is used for diagnostic
purposes. For wiring information, refer to section 5.6.
BRIB
T-interface Mode
BRIB
S-interface Mode
ISDN
Network
T
R
(100-Ohm)
T
R
(100-Ohm)
TE1 TE2 TE8
TE
Point to Point
1000 meters
TR
Point to Multi-point
200 meters (Short passive)
TE1 TE2 TE8
TR
TR
Point to Multi-point
500 meters
50 meters
