2.5.1 System Maximum Call Capacity
MAXIMUM PORT
EXTENSION TRUNK
iPECS-MG,
MPB100
SO DKTU/SLT PRI BRI CO IP
1st KSU 40 102* 80 40 60 80
108 80
Total
138
1st + 2nd KSU 88 120 80 80 80 80
120 80
Total
200
* DSIU DKT/SLT 6 + (4) DTIB24/SLIB24
- Max. DECT Terminal registration: 96
- Max. IP Phone registration: 120
- Max. VMIB or AAIB: 2 each
- Max. WTIB: 2 each
MAXIMUM PORT
EXTENSION TRUNK
iPECS-MG,
MPB300
SO DKTU/SLT PRI BRI CO IP
1st KSU 40 102** 120 40 60 120
108† 120
Total
138
1st KSU + 2nd KSU 88 198 180 88 132 180
216 180
Total
276
1st + 2nd + 3rd KSU 136 294 240 136 204 240
324 240
Total
414
** DSIU DKT/SLT 6 + (4) DTIB24/SLIB24
† DSIU DKT 6 + DSIU SLT 6 + (4) DTIB24/SLIB24
- Max. DECT Terminal registration: 192
- Max. IP Phone registration: 324
- Max. VMIB or AAIB: 3 each
- Max. WTIB: 3 each, when installing more than one WTIB4/8, install all WTIB4/8 in the same KSU
- If installed ports exceed capacity, the attendant keyset receives an alarm.
Simplified Maximum Port Chart
Extension
Boards
Total IP/TDM DECT
Trunk TOTAL
MPB100 120 120 96 80 200
MPB300 324 324 192 240 414
