iPECS-MG Hardware Description and Installation Manual Issue 1.1
System Overview August, 2010
7
2.4 General Specifications
2.4.1 Dimension and Weight
ITEM HEIGHT
(mm)
WIDTH
(mm)
DEPTH
(mm)
WEIGHT
(kg)
BKSU 170.2 440 325.4 6.2
EKSU 170.2 440 325.4 6.25
Digital Keyset* 268 203 124 0.9
Digital DSS/DLS Console* 154 175 111 0.4
Digital Door Phone Box 32 132 99 0.5
Digital Data Module 37 175 148 1.5
Base Station (600B) 170 220 57 0.46
GDC-33xH 145 50 35 0.15
GDC-34xH 131 49 32 0.102
Wireless
Terminal
GDC-400H 133 44 20 0.92
* Digital Keyset: LDP-7024D, Digital DSS: LDP-7048DSS, Digital Door Box: LDP-DPB
2.4.2 Environment
ITEM DEGREES
(
0
C)
DEGREES
(
0
C)
Operation Temperature 0~40 32~104
Optimum Operation Temperature 20~26 68~78
Storage Temperature 10~70 32~158
Relative Humidity 0~80% non-condensing
2.4.3 System Electrical
ITEM SPECIFICATION (PSU)
1. Power Supply
- AC Voltage Input 100 ~ 240 Volt AC @47~63Hz
- AC Power 350W
- AC Input Fuse
6.3A @ 250Volt AC
- DC Output Voltage + 5, 27 and + 30Volt DC
2. Battery Backup
- PSU Input Voltage 24Volt DC
- PSU Battery Fuse 15.0A @ 250Volt AC
- Charging Current Max. 1A
