Video Connection
Connect the VIDEO OUT (MONITOR) jack on
the unit to the video in jack on the TV using a
video cable.
You can hear the sound through the
system’s speakers.
Video Connection
Optional Equipment
Connection
AUX IN Connection
Connect an Output of auxiliary device to the
AUX Input (L/R) Connector.
If your TV has only one output for audio
(mono), connect it to the left (white) audio jack
on the unit.
AUX IN Connection
AUDIO IN (Portable IN)
Connection
Connect an OUTPUT of portable device (MP3
or PMP etc) to the P. IN connector.
AUDIO IN Connection
