Specifications
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 2.5 kg
External dimensions (W x H x D) 360 x 65 x 320 mm
Bus Power Suply (USB) DC 5V
500mA
Operating conditions Temperature 5°C to 35°C,
Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser,
wavelength 650 nm
Tuner FM/AM [MW]
FM Tuning Range 87.5 - 108.0 MHz or 87.50 - 108.00 MHz
FM Intermediate Frequency 128 kHz
AM Tuning Range 522 - 1,620 kHz, 520 - 1,710 kHz or
522 - 1,710kHz
AM Intermediate Frequency 45 kHz
Amplier
Stereo mode 45 W + 45 W (4Ω at 1 kHz, THD 10 %)
Surround mode Front 45 W + 45 W (THD 10 %)
Center 45 W
Surround 45 W + 45 W (4Ω at 1 kHz, THD 10 %)
Subwoofer 75 W (8Ω at 30 Hz, THD 10 %)
Speakers
Front/Rear/Center Speaker Passive Subwoofer
Type 1 Way 1 Speaker 1 Way 1 Speaker
Impedance 4 Ω 8 Ω
Rated Input Power 45 W 75 W
Max. Input Power 90 W 150 W
Net Dimensions (W x H x D) 103 x 111 x 94 mm 156 x 325 x 320 mm
Net Weight 0.39 kg 3.6 kg
Designs and specifications are subject to change without prior notice.
