DVD/CD Disc Drawer
b
Power (
1
/
)
)
c
Open/Close (
Z
)
d
Display window
e
Play/Pause (
B
/
X
), MONO/ST.
f
Stop (
x
)
g
Function (F)
Selects the function or input source.
h
TUNING (-/+)(
.>
), Skip/Search
You can search by pressing and holding
TUNING.
i
MIC 1, 2
j
USB port
You can play video, image and sound les
by connecting the USB device.
k
P.(Portable) IN port
You can enjoy music from portable device
on your unit.
l
Volume (VOL.)
Front panel
a b c d efg
l kj i h
Rear panel
a
Power cord.
b
Speaker terminal
c
ANTENNA connector (FM, AM)
d
VIDEO OUT connector
Connect to a TV with video inputs.
e
AUX connector
f
COMPONENT VIDEO OUT (Y PB PR)
Connect to a TV with Y Pb Pr inputs.
a b c de
f
