5-5
COMPOSITION OF CONTROL
Main PCB
Main PCB
(P/N : EBR77562701)
Oven Relay PCB
Oven Relay PCB
CN30
CN22CN21
CN24
CN11
CN13
CN09
CN17
CN16
CN25
CN03
CN26
CN32
CN1
CN103
CN102
CN17
CN16
CN101
CN100
