3-15
COMPONENT ACCESS
REMOVING THE OVEN TEMPERA
REMOVING THE OVEN TEMPERA
TURE SENSOR
TURE SENSOR
1. Turn off the electrical supply going to the range.
2. Open the oven door and remove the racks from
the oven.
3. Remove 2 screws from a bracket and pull the
oven temperature sensor forward in order to
access a connector and disconnect the wirings.
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
CAUTION
• Be careful when you work on the
electric range handling the sheet
metal part.
- Sharp edge may be present and you can cut
yourself.
To Next Page
