9-23
CHECKING FLOW CHART BY FAILURE
Is the value of thermistor
normal?
Check with the test mode
To enter the testmode, follow these steps:
1. press the “clear” key
2. press the “BAKE”, “BROIL” button
at the same time
3. press the “BAKE”, “BROIL” button
at the same time again.
Software version is displayed at the left digits.
4. press the NUM “3” button
Normal : the sensor value is from 70˚F
to 90˚F at room temp.
No
Replace the
Main PCB
4
Plug the unit
To Next Page
