28
206-4272
Ez Download Utility (Cont.)
(Continued from previous page)
Note: If there are no les of a particular le type on the USB device, that le type eld will not
be displayed in the Ez Download screen. For example, if there are no PTC les on the USB
device, you will not see a “PTC Software” eld in the Ez Download screen.
Note: Press on the Installer Remote or select BACK, as necessary, to return to the
STB Manager / USB Download Menu. To exit the STB Manager, select CANCEL (if accessed
from the STB menus, you may also press EXIT on the Installer Remote to exit). If you accessed
the STB Manager via the EZ-Manager Wizard, you will be returned to the last screen on display
before you selected the “USB Conguration” option. If you accessed the STB Manager via the
STB menus, you will be returned to program viewing.
7. If more than one USB memory device is currently connected to the STB, be sure to select the
USB device that contains the le(s) you wish to use. If necessary, use the Up/Down arrow
keys on the Installer Remote to select/highlight the Select USB Memory Device eld and
press OK. Then, use the arrow keys to select the appropriate USB device from the drop-down
list.
8. To select a le use the Up/Down arrows on the Installer Remote to select/highlight the
appropriate le type/pull-down eld, and then press OK to view a drop-down list of available
les. From the drop-down list, use the Up/Down arrow keys to select the desired le.
Note: The utility will only allow you to select one of each le type for downloading. For example,
if there are two les in the Ez Download Teach To STB (TLX) list, you can only select one or the
other of those two les.
Note: The initial default value for each le type is “None.” After the Ez Download utility is run,
a le is automatically created and stored on the USB device that was used. The le, which
will have a “.dzm” le extension, maintains a history of the le(s) previously used with the Ez
Download utility. The next time(s) you use this USB device with the Ez Download utility, the
le(s) selected for the last download will be pre-selected for the current download.
Note: If an STB Software (CPU) le is selected, STB SW Version and Update Version elds will
be displayed at the bottom right of the screen. Ensure the software version of the selected le is
the correct version before applying the update to this STB.
9. If a TLX le that includes an FTG Channel Map is selected, a Channel Tuning / Channel Banner
Display eld will be displayed at the right of the screen. If the FTG Channel Map comprises RF
channels and Aux inputs only (the latter designated by 130-0 through 137-0), you can choose
the format for the channel tuning/banner display. Use the arrow keys on the Installer Remote to
select Logical tuning or Physical tuning. A checkmark will appear at the left of the selected
option. Logical tuning is selected by default.
Note: If an FTG Channel Map includes IP channels, only logical tuning is available. Also, if the
selected TLX le does not include an FTG Channel Map, the message, “No Channel Map in
TLX le,” will be displayed at the right of the screen.
10. When you are ready to continue, use the arrow keys on the Installer Remote to select UPDATE,
and then press OK.
(Continued on next page)
