5.1 View Active Alarms
The Active Alarm screen displays all alarms that are occurring, up to a
maximum of 40.
A Current Alarm screen appears automatically whenever an alarm occurs—
except during setup. This screen can display only the two most recent
active alarms. To view any other active alarms, use the View Active Alarms
feature.
You may view active alarms at any time by using the following steps:
From the Main Menu, use the arrows to choose View Status, as
shown at right, and then press Enter.
From the View Status Menu, use the arrows to choose View
Active Alarms and press Enter.
5.1.1 Active Alarms
The Active Alarms screen displays up to 40 records; it shows any active
alarm and any Latched alarm that has not been cleared. Examples of alarms include inputs in alarm status
and failure of a standby device. When any alarms are present, the Active Alarms screen shows descriptive
details for each alarm:
the source of the alarm (for example, DEVICE_1)
the status of an input (CONTACT CLOSED)
If there are no active alarms, the screen displays the message:
NO ALARMS PRESENT
Viewing Additional Screens
There may be up to 40 records of alarm data.
To view additional records, use the arrows¯.
To return to the previous screen, press the ESC key.
Vertiv | Liebert® AC4 User Manual | 31
