Setup Outputs
For details on this feature, see Setup System - Setup Outputs on page50.
Setup Outputs
SETUP OUTPUTS
Setup output of device
Select output to edit
OUTPUTDEFINITION*******************************************
NO=NORMALLY OPENED
1=DEVICE_1NO-OP-ENC=NORMALLY CLOSED
2=DEVICE_2NO-ST-E
3=DEVICE_3NO-NU-DOP=OPERATING/ON
4=DEVICE_4NO-NU-DST=STANDBY MODE
5=RETURN TO SETUP MENUNU=NOT USED
6=RETURN TO MAIN MENU
D=DISABLE DEVICE ON AN ALARM CONDITION
SELECT A NUMBER:1E=LEAVE DEVICE OPERATING ON ALARM CONDITION
*******************************************
>SET TO NORMALLY OPENED(NO) OR NORMALLY CLOSED(NC)
>[NO]
>[
>COMMAND SUCCESSFUL
>DEVICE_1 TO OPERATING/ON(OP), STANDBY MODE(ST), NOT USED(NU)
>[OP]
>[
>COMMAND SUCCESSFUL
>DEVICE_1 TO ENABLE(E) OR DISABLE(D) DEVICE ON ALARM
>[E]
>[
>COMMAND SUCCESSFUL
Setup System Info
This section presents Service Terminal Interface screens for choices 1 through 9 in the Setup System
Information menu shown below. For details on this topic, see Setup System - Setup System Info on
page52.
