Liebert Nfinity User Manual

47
APPROXIMATE BATTERY RUN TIMES
12 Bay Frame, Internal and External (minutes)
Load
VA
Load
Watts
Quantity of Battery Modules Quantity of External Battery Cabinets w/Charger
1234567891011 1 2 3 4 5 6
20,000 14,000 - - - - 7 9 12 - - - - 17 46 78 119 158 199
19,500 13,650 - - - - 7 9 12 - - - - 18 48 81 123 163 205
19,000 13,300 - - - - 7 9 13 - - - - 19 49 84 127 169 212
18,500 12,950 - - - - 8 11 13 - - - - 20 51 87 131 174 219
18,000 12,600 - - - - 8 12 14 - - - - 20 53 90 136 180 226
17,500 12,250 - - - - 8 12 14 - - - - 21 55 93 141 187 235
17,000 11,900 - - - - 9 13 15 - - - - 22 57 97 146 194 243
16,500 11,550 - - - - 9 13 15 - - - - 23 59 101 152 201 253
16,000 11,200 - - - 7 9 13 17 19 - - - 24 62 106 157 209 262
15,500 10,850 - - - 7 10 13 17 20 - - - 25 64 112 164 217 272
15,000 10,500 - - - 7 11 14 18 21 - - - 27 67 118 171 226 284
14,500 10,150 - - - 8 12 15 19 22 - - - 28 70 124 178 236 296
14,000 9,800 - - - 8 13 16 20 23 - - - 29 73 129 186 246 309
13,500 9,450 - - - 8 13 16 20 24 - - - 31 77 135 195 258 323
13,000 9,100 - - - 9 13 17 21 25 - - - 32 81 142 205 270 338
12,500 8,750 - - - 10 14 18 22 26 - - - 34 85 149 215 283 355
12,000 8,400 - - 7 12 16 20 24 28 32 - - 36 90 157 226 298 373
11,500 8,050 - - 7 12 17 21 25 29 34 - - 38 95 166 239 314 392
11,000 7,700 - - 7 12 17 21 26 30 35 - - 40 101 176 252 332 413
10,500 7,350 - - 8 14 18 23 28 32 37 - - 43 109 186 267 352 435
10,000 7,000 - - 9 15 19 24 29 34 38 - - 46 118 198 283 396 459
9,500 6,650 - - 10 15 21 26 30 36 41 - - 49 126 211 302 396 486
9,000 6,300 - - 11 16 22 28 33 38 44 - - 53 135 226 323 422 517
8,500 5,950 - - 12 17 23 29 35 40 46 - - 57 146 243 347 449 551
8,000 5,600 - 7 13 19 25 31 37 43 49 55 - 62 157 262 373 480 589
7,500 5,250 - 8 14 21 28 34 40 47 53 59 - 67 171 283 402 517 630
7,000 4,900 - 8 16 23 30 36 43 50 57 64 - 73 186 309 435 558 678
6,500 4,550 - 9 17 24 32 40 47 55 62 69 - 81 205 339 473 605 734
6,000 4,200 - 11 19 24 36 43 51 60 68 76 - 90 226 373 517 659 798
5,500 3,850 - 12 21 23 39 47 56 66 74 82 - 101 252 413 569 722 875
5,000 3,500 - 14 23 28 42 52 61 72 80 90 - 118 283 459 630 798 970
4,500 3,150 - 15 25 37 47 57 67 78 88 98 - 135 323 516 704 891 1088
4,000 2,800 7 19 31 43 55 66 79 91 104 115 128 157 374 590 799 1016 1244
3,500 2,450 9 23 37 51 65 79 93 107 123 136 151 187 436 679 920 1177 1450
3,000 2,100 11 28 44 60 76 93 109 126 143 159 176 226 517 798 1090 1403 1731
2,500 1,750 14 33 52 71 89 109 128 147 167 185 205 283 630 970 1337 1729 2133
2,000 1,400 18 42 65 88 112 136 160 183 207 230 254 372 797 1240 1727 2233 2759
1,500 1,050 26 57 87 119 151 182 213 243 276 306 337 515 1085 1723 2400 3118 >3500
1,000 700 45 94 144 195 246 294 344 393 444 493 541 802 1739 2777 >3500 >3500 >3500
900 630 50 105 160 216 273 327 382 436 492 547 600 893 1958 3135 >3500 >3500 >3500
800 560 55 116 177 238 300 359 420 480 540 601 659 1013 2233 >3500 >3500 >3500 >3500
700 490 61 128 195 263 331 396 463 529 594 661 726 1168 2593 >3500 >3500 >3500 >3500
600 420 72 149 227 304 382 457 535 610 685 762 836 1416 3159 >3500 >3500 >3500 >3500
500 350 82 171 258 346 433 518 606 691 777 862 947 1739 >3500 >3500 >3500 >3500 >3500
Note: Back-up times in minutes are approximate and are based on resistive loading at an ambient temperature of 25°C
(77°F) under controlled conditions.
Backup times for External Battery Cabinets with Chargers do not include internal battery modules. To calculate total run
time, add External Battery Cabinet run time to run time listed for your particular configuration of internal battery modules.
When using an External Battery Cabinet(s), one External Battery Cable or External Battery Adapter must be ordered to
make the connection to the Nfinity UPS. Connections between multiple External Battery Cabinets are made using
contractor-supplied wiring and conduit.
