Battery Installation
22
Figure 10 Narrow battery cabinet, 27 in. (690mm) - rear view
Figure 11 Wide battery cabinet, 57 in. (1488mm) - front view
BCB plate
and BCB
Battery trays
Top cable
entry
Bottom cable
entry
Batteries
Battery tray
Anderson
connectors
Top cable entry
BCB plate
and BCB
Service
shelf
Battery tray
support
Bottom cable entry
