Specifications and Technical Data
53
8.0 SPECIFICATIONS AND TECHNICAL DATA
8.1 Lug Size and Torque Requirements
Use commercially available solderless lugs for the wire size required for your application. Refer to
Table 18. Connect wire to the lug using tools and procedures specified by the lug manufacturer.
Table 18 Torque specifications
Nut and Bolt CombinationS
Bolt Shaft Size
Grade 2 Standard
Electrical Connections
with Belleville Washers
Lb-in N-m Lb-in N-m
1/4 53 6.0 46 5.2
5/16 107 12 60 6.8
3/8 192 22 95 11
1/2 428 22 256 29
Circuit Breakers With Compression Lugs (For Power Wiring)
Wire Size or Range Lb-in N-m
#6 - #4 100 11
#3 - #1 125 14
1/0 - 2/0 150 17
3/0 - 200 MCM 200 23
250 - 400 MCM 250 28
500 - 700 MCM 300 34
Circuit Breakers With Compression Lugs (For Power Wiring)
Current Rating Lb-in N-m
400 - 1200 Amps 300.00 34.00
Terminal Block Compression Lugs (For Control Wiring)
AWG Wire Size or Range Lb-in N-m
#22 -#14 3.5 to 5.3 0.4 to 0.6
NOTE: Use the values in this table unless the equipment is labeled with a different torque value.
Table 19 Battery torque rating
Battery
Initial Torque
in-lb (N-m)
Annual Torque
in-lb (N-m)
UPS12-100FR 40 (4.5) 32 (3.48)
UPS12-140FR 40 (4.5) 32 (3.48)
UPS12-200FR 40 (4.5) 32 (3.48)
UPS12-270FR 40 (4.5) 32 (3.48)
UPS12-310FR 65 (7.4) 52 (5.88)
UPS12-370FR 65 (7.4) 52 (5.88)
UPS12-475FR 110 (12.4) 110 (12.4)
NPX-80FR 26 (2.9) 26 (2.9)
NPX-100FR 26 (2.9) 26 (2.9)
NPX-150FR 26 (2.9) 26 (2.9)
