Liebert NX 10kVA - Table 20 UPS Terminal

Specifications and Technical Data
54
Table 20 UPS terminal
Bypass input (single or dual input unit)
Unit
Rating
Nominal
Input
Current
Maximum
Input
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10 28 35 42 45 6M (1/4”) 54105 62204
15 42 53 63 70 6M (1/4”) 54106 62204
20 56 70 84 90 6M (1/4”) 54107 62204
30 83.3 104 125 125 6M (1/4”) 54152 62205
Rectifier Input (for Dual input unit only)
Unit
Rating
Nominal
Input
Current
Maximum
Input
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10 24.9 31 37 40 6M (1/4”) 54130 62204
15 37.3 47 56 60 6M (1/4”) 54106 62204
20 49.8 62 75 80 6M (1/4”) 54107 62204
30 74.7 93 112 125 6M (1/4”) 54152 62205
Output
Unit
Rating
Nominal
Output
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10 28 35 35 6M (1/4”) 54130 62204
15 42 53 60 6M (1/4”) 54106 62204
20 56 70 70 6M (1/4”) 54106 62204
30 84 105 110 6M (1/4”) 54108 62205
Battery
Unit
Rating
Battery
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10 37 37 40 6M (1/4”) 54130 62204
15 55 55 60 6M (1/4”) 54106 62204
20 73 73 80 8M (5/16”) 54142 62212
30 110 110 125 8M (5/16”) 54153 62212
