Specifications and Technical Data
57
8.2 Cable Lengths: Floor to Connection Point Inside UPS
To help calculate the total cable length required, refer to Table 26 for the distance from the floor to
selected connection points inside the NX. Determine the cable length required to reach the NX, then
add the appropriate length from the table and adequate slack for repair and maintenance.
Table 23 Battery cabinet physical characteristics
Battery Cabinet
Type
Dimensions
WxDxH in. (mm)
Net Weight Without
Batteries, lb. (kg)
Short Narrow
27.2x31.4x63
(690x825x1600)
551
(250)
Short Wide
58.5x31.4x63
(1488x825x1600)
889
(400)
Table 24 Maintenance Bypass Cabinet weights
UPS
Rating
Maintenance Bypass Cabinet Style, lb. (kg)
ABCD E LJKM N
10kVA 408 (185) 545 (247) 675 (306) 602 (273) 732 (332) 670 (304) 403 (183) 540 (245) 597 (271) 728 (330)
15kVA 408 (185) 567 (257) 728 (330) 659 (299) 822 (373) 723 (328) 403 (183) 562 (255) 655 (297) 818 (371)
20kVA 408 (185) 646 (293) 842 (382) 739 (335) 935 (424) 838 (380) 403 (183) 642 (291) 734 (333) 930 (422)
30kVA 408 (185) 694 (315) 893 (405) 807 (366) 1027 (466) 888 (403) 403 (183) 690 (313) 802 (364) 1023 (464)
Table 25 Maintenance Bypass Cabinet dimensions
Unit Width Depth Height
inch 27.2 31.4 63
mm 690 825 1600
Table 26 Distance to connection points on the NX
Connection Point on UPS
Distance
From
Floor
in. (mm)
From
Top of Unit
in. (mm)
Bypass AC input supply 30 (750) 30 (750)
UPS output AC 30 (750) 30 (750)
Neutral busbars—Input and Output 11 (280) 55 (1397
Battery power 16 (400) 58 (1474)
Auxiliary cables: Monitor board (U2) 60 (1500) 20 (508)
Communications 55 (1400) 25 (635)
Ground 8 (197) 56 (14227)
