6.4.4 Inverter Output
6.4.5 Bypass Input
Table 13 Inverter output
Rated Power 10kVA 15kVA 20kVA 30kVA
Rated voltage, VAC 120/208
Supply 3-phase, 4-wire plus ground
Frequency, Hz 50 / 60
Rated Power, kVA 10152030
Rated Power, kW 8 12 16 24
Three -phase transient overload,
min. load
10 minutes - 105-125% load
1 minute - 126-150% load
Voltage Regulation % ±1.0% three-phase RMS average for a balanced three-phase load
±2.0% three-phase RMS average for a 100% unbalanced load
Frequency Regulation % Nominal frequency regulation is ±0.05% in single module mode,
and+/- 0.25% in parallel mode.
Maximum rate of change of
frequency, Hz/sec
For single mode, the slew rate is adjustable from 0.1Hz/s to 3Hz/s
Current rating of neutral cable, A 1.5 x input current
Table 14 Linear load derating
PF
Lagging Leading
0.50.60.70.80.91.00.90.80.70.60.5
K (200V) 1.00 1.00 1.00 1.00 0.88 0.80 0.75 0.73 0.72 0.71 0.71
K (208V) 1.00 1.00 1.00 1.00 0.88 0.80 0.75 0.73 0.72 0.71 0.71
Table 15 Bypass input
Rated Power 10kVA 15kVA 20kVA 30kVA
Rated voltage, VAC 120/208
Supply Three-phase, 4-wire plus ground
Rated Current, A
200VAC, A 32486496
208VAC, A 28425683
Bypass voltage tolerance %
Upper limit: +10%, +15% or +20%
Lower limit: -10%, -20%, -30% or -40%
Upper limit default: +15%
Lower limit default: -20%
Delay time to recognize bypass voltage
returned to window, sec.
2
Inverter output voltage window % ± 10
Frequency, Hz 50 / 60
Input frequency tolerance % ± 10 or ± 20%; default ±10%
Maximum frequency slew rate, Hz/sec For single mode, the slew rate should be adjustable from 0.1Hz/s to 3Hz/s
Current rating of neutral cable, A 1.5 x input current
Bypass overload capacity
(all ratings)
Time
Long-term operation:
10 minutes:
100milliseconds:
Load
<135% load
135% - 170% load
1000% full UPS rated output current
