Two boxes are available depending on the UPS power rating.
The weights listed above do not include package.
The circuit breaker has the following features:
• Short-circuit protection.
• Protection against battery cabinet and ups connection errors (polarity reversal +/-).
The battery circuit breaker boxes are of the same size for the 10 kVA to 30 kVA UPS, but switch
capacity are different.
The information shown in Figure 22 applies to both sizes.
The BCB box contains a battery isolating circuit breaker.
The BCB box should be fitted as close as possible to the battery and connected to the UPS equipment
as Figure 22 illustrates.
Table 7 Available battery circuit breaker boxes
UPS
Dimensions (in)
H-W-D Circuit Breaker
10-15 kVA 32.25x20.25x8.3 70A
20-30 kVA 32.25x20.25x8.3 125A
