imultaneously press and hold down
on the power supply to the system to light the second LED.
the two red LEDs will now fl ash.
Being a single leaf system, staggering will not be indicated
for the manoeuvres below.
LEAF 2 CLOSURE STOP PLATE IDENTIFICATION:
, holding it down until leaf
lowly reaches and pushes for a few seconds against the
, holding it down until leaf
lowly reaches and pushes for a few seconds against the
ATTENTION: if a single operator is used, connect the stop plates to the motor 1 terminals: 34-32 and 33-32; jumper
the motor 2 stop plate inputs: terminals 31-32 and 30-32.
