The REDCAT is designed to integrate with multiple audio
sources allowing other instructional technologies to be
clearly heard throughout the classroom.
3. AUDIO INTEGRATION
Projector
DVD/VCR
Te acher’s
REDMIKE
Projector
Audio In
Audio Out
IR Tr ansmission
Video In
Audio Out
Video Out
VGA Out
REDCAT
REDCAT BLOCK DIAGRAM
