REDCAT User Manual
17 | REDCAT User Manual
4. CONNECTING THE POWER SUPPLY
1. Locate the power supply and AC power cord. Connect the AC power cord into
the DC power supply.
2. Place the power supply into the REDCAT base as shown. If desired, remove the
plastic cover of the included Velcro strip and attach the supply to the Velcro for
a more secure t.
3. Insert the DC connector into the “DC POWER INPUT” connector on the bottom
of the REDCAT and plug the other end to an electrical outlet.
1. Ensure all cables are appropriately routed out of walking paths and work areas to
prevent safety hazards to individuals in the room.
2. The REDCAT packing material should be kept for warranty shipping purposes.
3. Proceed to initial set-up to test system performance.
FINAL CHECK
Leave microphones charging so they are ready for use.
Microphones will need to be charged on a daily basis.
1
2
3
