WTR Series
Product Capabilities and Features / Unit Weights
L120 Installation & Maintenance Manual 120-11000 A
Inspection and Recording
Upon receipt of the actuator, inspect the condition of the equipment and record nameplate
information as follows:
1. Carefully remove actuator from shipping carton or skid. Thoroughly examine the
equipment for any physical damage that may have occurred during shipment. If
damaged, immediately report the damage to the transport company.
2. Record the unit nameplate information for future reference; i.e. ordering parts,
obtaining further information.
Storage Procedures
NOTE: The following are our recommended storage procedures to retain maximum product
integrity during short-term storage. Failure to comply with recommended procedures will
void the warranty. For longer-term storage, contact Limitorque for procedures and
recommendations.
Short-Term Storage (less than 1 year)
Units are not weatherproof until properly installed on the valve or prepared for storage.
Store units in a clean, dry, protected warehouse from excessive vibration and rapid temper-
ature changes. If the units must be stored outside, they must be stored off the ground, high
enough to prevent them from being immersed in water or buried by snow.
1. Position the actuator in storage with motor and switch compartment horizontal.
2. Connect the internal heaters (if supplied) or place desiccant in the switch compartment.
3. Replace all plastic caps or plugs with pipe plugs and ensure that all covers are tight.
4. If the actuator is mounted on a valve and the stem protrudes from the unit, a suitable stem
cover must be provided.
Unit Weights
The approximate L120 actuator weights are provided below:
Table 1 – Unit weights
Unit Size Control Types Drive 1 weight (lbs/kg) Drive 2 Weight (lbs/kg)
Top HW Side HW Top HW Side HW
lbs kg lbs kg lbs kg lbs kg
L120-10 NCU 100 45 112 51 107 49 119 54
BIC 115 52 127 58 122 55 134 61
UEC/CLAMSHELL 140 64 152 69 147 67 159 72
L120-20 NCU 140 64 158 72 153 69 171 78
BIC 155 70 173 78 168 76 186 84
UEC/CLAMSHELL 180 82 198 90 193 88 211 96
L120-40 NCU 190 86 216 98 212 96 238 108
BIC 205 93 231 105 227 103 253 115
UEC/CLAMSHELL 230 105 256 116 252 114 278 126
