Instruction Manual for TECH-system type 239
______________________________________________________________________________
Page 29 of 39 june 2020 ver. 09
LINAK Danmark A/S - Mønstedsvej 9 8600 Silkeborg - Telefon 86803611 - www.linak.dk
Parameter settings
As standard, the TR-EM-239 motor control unit has 11 parameters that can be set to match the individual
application. The TR-EM-239 with advanced software version 1.4 has 14 parameters. For it to be possible
to change these parameters, programming unit TR-EM-236 must be connected to the motor control unit.
NB! The control unit must be connected to a power supply while programming.
Programming unit TR-EM-236
Press ARROW DOWN for 2 seconds to call up the main menu of the programming unit. In the main menu,
use ARROW UP or ARROW DOWN to select the menu item required. To open the menu in question, click
the + (plus) button.
To alter the parameter values, select the “Load & Edit” menu item
Use the arrow keys to select the parameter you wish to alter. The parameter selected is shown in the
display as <1 / 11>, which means parameter 1 of 11. The value is presented in square brackets [ ] and
can be changed by pressing the plus or minus buttons.
Parameter in question. In
this case, 1 of 11.
