Instruction Manual for TECH-system type 239
______________________________________________________________________________
Page 32 of 39 june 2020 ver. 09
LINAK Danmark A/S - Mønstedsvej 9 8600 Silkeborg - Telefon 86803611 - www.linak.dk
Explanation of parameters
The following section presents a more detailed explanation of the individual parameters. Set the
parameters by entering a number in the display.
NB! LINAK´s recommended parameters are presented in { } after each description below.
Speed: This parameter makes it possible to set the operating speed of
the actuators. The speed is stated in %. Max. speed = 100%.
The following options are available:
40 – 100 {100}
HOME speed: This parameter makes it possible to set the reduced speed with which the
actuators are to return to their starting position. The speed is stated in %. Max.
speed = 60%.
The following options are available:
20 – 60 {60}
Start ramp: This parameter makes it possible to set the start ramp to a soft start. The ramp
time is measured in seconds from 0–2.0 sec.
The following options are available:
0 to 20 {5}
Stop ramp: This parameter makes it possible to set the start ramp to a soft start. The ramp
time is measured in seconds from 0–2.0 sec.
The following options are available:
0 to 20 {0}
Current limit: This parameter is used to state the max. permitted power consumption for each
actuator connected. The power limit is measured in Amp. From 1–20 A.
The following options are available:
10 to 200 {50} (should be checked in every case)
Deviation in pulses: This parameter is used to state the permissible deviation in feedback from
the actuators before the control unit synchronises. The deviation is stated
between 3–50 pulses.
The following options are available:
3 to 50 {10}
1
3
4
5
6
2
