Instruction Manual for TECH-system type 239
______________________________________________________________________________
Page 15 of 39 june 2020 ver. 09
LINAK Danmark A/S - Mønstedsvej 9 8600 Silkeborg - Telefon 86803611 - www.linak.dk
Fitting a DC-DC converter
When using a pair of LA20, LA23, LA35, LA40 actuator or BL1 Lift column, the DC voltage to the Hall
sensor in the actuator must be regulated to a constant 12 V. To do this, fit the DC-DC converter, EM-311-
DK
The converter is easily fitted in the TR-EM-239-T-230 box beside the transformer. The converter must be
ordered separately.
DC-DC converter
Order no.: EM-311-DK
Installing the DC-DC converter:
To connect the converter, see diagram on page 23.
