4) LA12
Drawings
Figure 6
Colour codes:
S Black
BR Brown
R Red
O Orange
GU Yellow
G Grey
BL Blue
V Purple
GR Green
HV White
5) LA30, LA30S, LA32 and LA34 with potentiometer
6) LA30, LA30S and LA32 with optical encoder
