T 16, T 18 and T 20 pallet trucks are high-performance
machines, designed for intensive use.
Their small size, ease of handling and responsiveness
make them particularly suitable for loading and unloading
The range of these machines covers the capacities of
Power is supplied by a 24 V high-capacity drive battery.
An automatically ventilated electric motor, equipped with
sensors on the most powerful models to regulate the
speed, drives the drive wheel through a 2-stage gearbox:
- 1st stage by belt and pulley
- 2nd stage by gears greased for life contained in a
The traction motor is controlled by a speed controller with
MOSFET transistors, specifically developed by LINDE for
This controller offers excellent efficiency and allows opti-
mum control of the speed, acceleration and reverse
On the most recent models equipped with the LDC (Linde
Digital Control) controller, this is controlled by a
microprocessor which offers numerous adjustment
possibilities and is equipped with a failure auto-diagnosis
As an alternative, there is a more traditional starting
system with resistors and contactors.
On this latter model, the speed changes are, however,
controlled by an electronic circuit.
A compact motor pump unit, consisting of a motor, pump,
tank, filter and descent valve, supplies the two lifting jac
arms, activating the bogies.
corrosion-resistant, and the pivot rings are self-lubricating.
A long, sturdy and ergonomic drawbar allows the truck
driver to steer the drive and guide wheel effortlessly.
The various controls - forward, reverse, raising and
lowering of the fork and horn - are grouped
For safety reasons, the drawbar
, under the action of a gas
A shoe brake situated on the countershaft of the gearbox
is controlled by the position of the drawbar.
The parking brake is applied automatically when the
Gradual and controlled reverse braking is obtained by the
inversion of the direction of movement.
On some models, this braking is automatically controlled
on the release of the accelerator; this is the LBC (Linde
Brake Control) automatic braking system.
This totally automatic charger, of the high-frequency
switching power supply type, provides full and satisfactory
recharging of the 24 V batteries from 160 to 240 Ah.
The charging is controlled by a microprocessor and
indicator lights situated on the control panel of the pallet
- Single-phase supply 220 V 50 Hz **
- Effective current input 8 A
- Charging current 30 A at start of charging
**Other voltages and frequencies available as an option.
