Mechanical brakes
Releasing the tiller applies the brake.
The braking is progressive, depending on the position of
the tiller in tilt areas (1) and (2).
Reverse current brake
Electrical braking can be obtained by reversing the direc-
tion of travel.
-
Press t
he trav
el cont
rol swi
tch (3)
to th
e opposi
te dir
ec-
tion of travel until the truck stops, then release the switch.
NOTE
-
On r
esistanc
e mo
dels,
perform
this
manoeu
ver sl
owly
and at low speed.
-
On tr
ucks e
quipp
ed wit
h puls
e cont
rol,
braki
ng is
controlled by the pulse control and is very gradual.
LBC * automatic braking (Linde Brake Con-
trol)
-
Rele
ase t
he ac
cele
rat
or bu
tte
rfl
y valv
e
-
The
pall
et
truc
k is
brak
ed a
uto
mat
ical
ly b
y rev
erse
current until it stops .
* Option
Lifting device
ATTENTION
The lifting device should be used only for
authorized applications. The operator must be
instructed in the use of the lifting device.
-
Tu
rn th
e key s
wi
tc
h clo
ckw
ise
.
Operation
Raising the forks
-
Pre
ss th
e cont
rol sw
itc
h (4) on t
he ti
ller
.
Lowering the forks
-
Pre
ss th
e cont
rol sw
itc
h (5) on t
he ti
ller
.
Operating of the horn
-
Pre
ss t
he bu
tto
n (6
) on t
he t
ille
r.
Braking, Raising, Lowering, Horn
