D9U001ES1-0110_02
25
9.2.1 Braked Bed
To brake the bed:
► Press red Brake pedal (1 or 2) to the lower position.
All four castors are braked.
9.2.2 Forward Movement (Steering)
To set forward movement:
► Press green Drive pedal (3 or 4) to the lower position.
The front left castor is locked after its forward movement was reached. The bed moves straight ahead.
If the bed is equipped with a fth castor, this castor determines the direction of movement.
Fig. Positions of Brake pedals
2
2
1
1
1. Brake Pedal (standard) - RED
2. Brake Pedal (optional) - RED
Fig. Positions of Drive pedals
4
4
3
3
3. Drive Pedal (standard) - GREEN
4. Drive Pedal (optional) - GREEN
