12.5 Monitor Shelf
Monitor shelf is intended for carrying a monitor when the monitor shelf is folded inwards the bed (4). When the monitor shelf is
folded outwards the bed (3) it serves for writing. When the monitor shelf is folded down (2) it serves as a foot board. Monitor shelf
is equipped with straps to x a monitor on the monitor shelf. Maximum load of the monitor shelf in position for carrying a monitor (4)
and for writing (3) is 15 kg.
HOOKS
The position of hooks placed on the frame of Monitor Shelf can
be changed to a more convenient position!
Respect maximum load of the Monitor Shelf when hanging
things on the hooks!
Fig. Instruction for placement of the monitor shelf to
the bed end
Fig. Monitor shelf
(on foot end)
4
2
2
3
1
To change position of the board:
► Pull a control lever (1).
► Change position of the board.
► Release the control lever (1) in order to the control lever latches.
► Move the board up and down to ensure the board is xed.
