D9U001ES1-0110_02
47
To extend foldable infusion stand:
► Extend the foldable infusion stand by taking its telescopic part out.
To facilitate procedure put control ring (3) up during extending.
To shorten foldable infusion stand:
► Put control ring (3) up during inserting the telescopic part
into the foldable infusion stand.
To prepare hooks of infusion stand:
► Take a hook out (4).
WARNING!
Keep dry locks of the foldable infusion stands!
► Do not oil or lubricate the locks of the foldable infusion stands!
12.4 Infusion Stand
Infusion Stand is intended for carrying IV bags or baskets for intravenous solutions.
It can be located in bushings for accessories at a bed corner.
Maximum load of one hook is 5 kg.
Fig. Infusion stand (at
bed end corners)
Fig. Positions for Infusion Stand
