D9U001ES1-0110_02
55
14 Troubleshooting
Error/Fault Cause Solution
Faulty Mattress Support Platform Height
Adjustment
Obstacle on the undercarriage cover Remove the obstacle.
Obstacle under the pedals Remove the obstacle.
Faulty pedal. Notify the manufacturer´s service
department.
Lowering Backrest from the upright position
not possible
Obstacle under the Backrest or in the drive
mechanism.
Remove the obstacle
Backrest Release Handle is defective Notify the manufacturer´s service
department.
Adjusting Siderails not possible Obstacle in the Siderail Release Mechanism Remove the obstacle.
Siderail Release Mechanism is defective. Notify the manufacturer´s service
department.
Faulty brakes Obstacle blocking brakes mechanically Remove the obstacle.
The brake mechanism is defective Notify the manufacturer´s service
department
