10 Equipment
10.1 Accessory Holders (optional)
Accessory holders are intended for hanging accessories.
10.2 Undercarriage Cover
CAUTION!
Risk of material damage due to objects on the undercarriage cover!
► Do not place objects on the undercarriage cover outside storage space!
► Respect dimensions of objects placed in storage spaces of the undercarriage cover
during lifting, lowering and tilting of the bed!
There are 2 types of storage spaces of the undercarriage cover. Longitudinal storage spaces (1) are intended for oxygen bottle
(with capacity 10 litres (type E only), 5 litres or less). Suitable oxygen bottle can be xed with quick-release strap. Rectangular
storage space (2) is intended for objects with maximum height of 25 cm.
Fig. Storage spaces (Undecarriage Cover)
12
1
Fig. Accessory holders (on side)
