Link G4 Storm - Analogue Input Set-up

First Time Setup 55
© 2009 Link
1. Click on ‘Digital Inputs’ then select the first Digital
Input that requires configuration:
a. Select the required ‘Function’ for the Digital
Input channel.
b. Configure the channel as required. Refer to
PCLink Tuning Software’s online help for more
information on adjustments.
c. Confirm the operation of the Digital Input by
opening the Digital Inputs tab of the runtime
values (lower area of PCLink Tuning Software
screen).
2. Configure each additional Digital Input channel.
Ensure unused channels have their ‘Function’ set
to ‘OFF’.
3. Perform a Store to permanently save changes to
the ECU by pressing F4.
Analogue Input Set-up
This section configures the ECU’s Analogue Input channels for the devices they have been
wired to. Preparing a configuration table as shown in Section 2.7 will greatly simplify set-up
of Analogue Inputs. Essential inputs are configured in this section. All steps must be
performed on all applications.
