Linksys LAPAC1750PRO User Manual

27
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Generate SSL Certificate
Generate SSL
Certificate
Click Generate to generate a new HTTP SSL certificate
for the secure Web server. This should be done once
the access point has an IP address to ensure that the
common name for the certificate matches the IP address
of the access point. Generating a new SSL certificate will
restart the secure Web server. The secure connection
will not work until the new certificate is accepted on the
browser.
SSL Certificate File Status
Certificate File
Present
Indicates if the HTTP SSL Certificate file is present. Range
is either Yes or No.
Certificate
Expiration
Date
Indicates when the HTTP SSL Certificate file will expire.
The range is a valid date.
Certificate
Issuer
Common
Name
The Common Name attribute of the server certificate.
The range is a valid string. For example, /CN=self-
signed/OU=Linksys LLC.
L=Irvine
ST=California
C=US
To Get the Current HTTP SSL Certificate
Download
Method
Select either HTTP/HTTPS or TFTP option. Click
Download to save the current HTTP SSL Certificate as a
backup file to your PC.
HTTP SSL
Certificate File
This field is available when the selected download
method is TFTP. Enter the filename of the certificate. The
filename is a 256-byte alphanumeric string. The default
is “Mini_httpd.pem”.
Note: File name should not contain spaces, < , > , | , \ ,
/ , : , (, ), & , ; , # , ?, *, $, %, ‘, “, and successive ‘.’ .
Server IP The IPv4 or IPv6 address of the TFTP server where the
file will be downloaded. The default is “0.0.0.0”.
Upload SSL Certificate
Upload
Method
Select the upload method:
• HTTP/HTTPS: Upload the file by using a Web
browser
• TFTP: Upload the file from a TFTP server
HTTP SSL
Certificate File
If the selected upload method is HTTP, click the Browse
button to browse to the file to upload to the AP.
If the selected upload method is TFTP, this field displays
a text box. Enter the filename of the certificate to upload
to the AP.
Note: File name should not contain spaces, < , > , | , \ ,
/ , : , (, ), & , ; , # , ?, *, $, %, ‘, “, and successive ‘.’ .
Server IP The IPv4 or IPv6 address of the TFTP server where the
file is located. The default is “0.0.0.0.”
NOTE:
Click Save to apply the changes and save the changes to startup
configuration file. If you disable the protocol you are currently using to
access the AP management interface, the current connection will end
and you will not be able to access the AP by using that protocol until it is
enabled.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
