Linksys LAPAC1750PRO User Manual

49
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Enable RADIUS
Accounting
Select this option to track and measure the resources
a particular user has consumed such as system time,
amount of data transmitted and received, and so on.
If you enable RADIUS accounting, it is enabled for the
primary RADIUS server and all backup servers.
Active Server The RADIUS IP address and key for up to four RADIUS
servers can be configured on the AP. Select which of
the four RADIUS servers the VAP should contact to
authenticate wireless clients.
Broadcast Key
Refresh Rate
Enter a value to set the interval at which the AP will
refresh session (unicast) keys for each client associated
to the VAP.
The valid range is 0–86400 seconds. A value of 0
indicates that the broadcast key is not refreshed.
Session Key
Refresh Rate
Enter a value to set the interval at which the AP will
refresh session (unicast) keys for each client associated
to the VAP.
Scheduler
The Radio and VAP Scheduler is a standalone LAPAC1750PRO Access Point
feature. To configure the Radio and VAP scheduler, select the Scheduler tab in
the Manage section. The Radio and VAP Scheduler allows you to configure a
rule with a specific time interval for VAPs or radios to be operational, thereby
automating the enabling or disabling of the VAPs and radios.
One of the ways you can use this feature is to schedule radios to operate
only during the office working hours in order to achieve security and reduce
power consumption. You can also use the scheduler to allow access to VAPs for
wireless clients only during specific times of day.
Each rule specifies the start time, end time and day (or days) of the week
the radio or VAP can be operational. The rules are periodic in nature and are
repeated every week.
A valid rule must contain all of the following parameters:
• Days of the Week
• Start Time (hour and minutes)
• End Time (hour and minutes)
Only valid rules are added to the profile. Up to 16 rules are grouped together
to form a scheduling profile. Any two entries belonging to the same profile
must not overlap. The time granularity for the schedules is one minute. The
LAPAC1750PRO Access Point supports up to 16 profiles.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
