Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Destination Port Select this field to include a destination port in the
match condition for the rule. The destination port is
identified in the datagram header.
Once you select the field, choose the port name or
enter the port number.
Select From List
Select the keyword associated with the destination
port to match:
• ftp
• ftpdata
• http
• smtp
• snmp
• telnet
• tftp
• www
Each of these keywords translates into its equivalent
port number.
Match to Port
Enter the IANA port number to match to the destination
port identified in the datagram header. The port range
is 0–65535 and includes three different types of ports:
• 0–1023: Well Known Ports
• 1024–49151: Registered Ports
• 49152–65535: Dynamic and/or Private Ports
EtherType Select the EtherType field to compare the match criteria
against the value in the header of an Ethernet frame.
Select an EtherType keyword or enter an EtherType
value to specify the match criteria.
Select from List Select
Select one of the following protocol types:
• appletalk
• arp
• ipv4
• ipv6
• ipx
• netbios
• pppoe
Match to Value
Enter a custom protocol identifier to which packets are
matched. The value is a four-digit hexadecimal number
in the range of 0600–FFFF.
Class of Service Select the field and enter a class of service 802.1p user
priority value to be matched for the packets. The valid
range is 0–7.
Source MAC
Address
Select this field and enter the source MAC address to
compare against an Ethernet frame.
Source MAC Mask Enter the source MAC address mask specifying which
bits in the destination MAC to compare against an
Ethernet frame.
An f indicates that the address bit is significant, and a
0 indicates that the address bit is to be ignored. A MAC
mask of ff:ff:ff:ff:ff:ff matches a single MAC address.
Destination MAC
Address
Select this field and enter the destination MAC address
to compare against an Ethernet frame.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
