Linksys RE7000 User Manual

8
If it blink s amber , the connection failed. You may try again by
repeating step 3 or try brow ser -based setup on page 9 .
4. Extend your 5 GHz network.
You may skip this step if your router does not have a 5 GHz network or if you don't want to
extend that network.
a. Press the WPS button on the side of your router again. Within the next two minutes
complete step 4b.
b. Press the WPS button on your range extender again.
The WPS button will light up and the indicator LED on the front of your range
extender will start to blink green.
Watc
h the indicator LED on the front of your range extender to verify whether the
connection was successful.
If it turns solid green , the connection was successful.
If it starts to blink amber before it turns solid green, the connection
failed. You may try again by repeating step 4.
5. Move your range extender to an ideal spot.
Unplug your range extender and plug it back in midway between your router and the area
without Wi -
Fi. Using your mobile device or laptop, be sure you have at least two bars
(around 50%) of your router’s Wi -Fi signal at that location. If you don’t have two bars,
move the range extender closer to the router.
6. Check indicator LED for connection quality.
It can take up to a minute for the ranger extender to boot up after moving it. During t his
period you will see the blinking green LED once again.
o
Solid green Ready to
use.

Linksys RE7000 Specifications

General

Type	Network repeater
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	900 m
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	1900 Mbit/s
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	81 mm
Width	126 mm
Height	46 mm
Weight	255 g
