LinRS Interface
14.3Get error counters of error log and total occurred errors
With the command “Get error counters of error log and total occurred errors” the slave
answers with the number of logged errors and the number of occurred error (which is a free
running counter).
Request: Get error counters of error log and total occurred errors
Byte
Offset
Value Description
0 01h Fix ID telegram start
1 11h MACID
2 03h Data length
3 02h Fix ID start data
4 02h Sub ID: Get error counters
5 07h Main ID: Read Error Info Message Group
6 04h Fix ID telegram end
Response: Get error counters of error log and total occurred errors
Byte
Offset
Value Description
0 01h Fix ID telegram start
1 11h MACID
2 08h Data length
3 02h Fix ID start data
4 72h Sub ID: Response Get error short text of actual error
5 00h Main ID: Response Message
6 00h Communication State ok
7 15h Low byte Number of error log entries
8 00h High byte Number of error log entries
9 4Eh Low byte Number of occurred errors
10 00h High byte Number of occurred errors
11 04h Fix ID telegram end
Example:
Tx: 01 11 03 02 02 07 04
Rx: 01 11 08 02 72 00 00 15 00 90 00 04
The slave responds 21 (15h) Logged errors (=buffer size) and 144 (90h) occurred errors.
Page 50/59 User Manual LinRS Interface / 03/10/2017 NTI AG / LinMot
