LinRS Interface
3.2 ID and Baud Rate Selection
With the default parametrization the baud rate can be selected over S1 and the ID is selected
over S2.
3.2.1 Baud Rate Selection
The baud rate can be defined over the S1 hex switch (default setting) or by parameter value.
S1 Baud Rate Code Table
S1 Value Selected Baud Rate
0h Undefined Baud Rate
1h 4800Bit/s
2h 9600 Bit/s
3h 19200 Bit/s
4h 38400 Bit/s
5h 57600 Bit/s
6h 115200 Bit/s
7h Undefined Baud Rate
8h-Fh Undefined Baud Rate
3.2.2 ID Selection
Like the baud rate the protocol ID can be defined over the S2 hex switch (default setting), by
parameter value or by the S1&S2 hex switches.
S2 ID code table
S2 Value Selected MACID
0h MACID = 00h
1h MACID = 01h
2h MACID = 02h
... ...
Fh MACID = 0Fh
S1&S2 ID code table
S1 Value S2 Value Selected MACID
0h 0h MACID = 00h
0h 1h MACID = 01h
0h 2h MACID = 02h
... ... ...
1h 0h MACID = 10h
... ... ...
Fh Fh MACID = FFh
Page 8/59 User Manual LinRS Interface / 03/10/2017 NTI AG / LinMot
