Parity Defines the parity bit behaviour.
LinRS\ RS Config\ Parity
None No parity bit
Even Even parity bit
Odd Odd parity bit
Protocol Config In this section the protocol can be configured.
MACID In this section the MAC ID (drive number) can be configured.
MACID Source Select
The MACID parameter defines the source of the MACID (Node
Address).
C1100, E1x00:
LinRS\ Protocol Config\ MACID\ MACID Source Select
By Hex Switch S2 Not on B1100: The MACID is determined by the
hex switch S2 (default)
By Hex Switches
S1 and S2
Not on B1100: The MACID is determined by the
two hex switches S1 and S2
By Parameter The MACID is determined by parameter setting
B1100:
OS\ Communication\ MACID\ MACID Source Select
By Dig In 1 The MACID is defined by DigIn1 (X13.14) at
power up. 0V = ID 0, 24V = ID 1
By Dig In 2..1 The MACID is defined by DigIn2 .. 1 (X13.2 and
X13.14) at power up. DigIn2 is the most, DigIn1
the least significant bit. ( 00b = ID 0, 11b = ID 3)
By Dig In 3..1 The MACID is defined by DigIn3 .. 1 (X13.15,
X13.2 and X13.14) at power up. DigIn3 is the
most, DigIn1 the least significant bit. ( 000b = ID
0, 111b = ID 7)
By Dig In 4..1 The MACID is defined by DigIn4 .. 1 (X13.3,
X13.15, X13.2 and X13.14) at power up. DigIn4
is the most, DigIn1 the least significant bit.
( 0000b = ID 0, 1111b = ID 15)
By Dig In 5..1 The MACID is defined by DigIn5 .. 1 (X13.16,
X13.3, X13.15, X13.2 and X13.14) at power up.
DigIn5 is the most, DigIn1 the least significant
bit. ( 00000b = ID 0, 11111b = ID 31)
By Dig In 6..1 The MACID is defined by DigIn6 .. 1 (X13.4,
X13.16, X13.3, X13.15, X13.2 and X13.14) at
power up. DigIn6 is the most, DigIn1 the least
significant bit. ( 000000b = ID 0, 111111b = ID
63)
By Dig In 1 +
Offset
The MACID is defined by DigIn1 (X14.14) at
power up plus the value of 6081h (MACID
Parameter Value) as offset. 0V = ID 0, 24V = ID
1 (plus offset).
By Dig In 2..1 +
Offset
The MACID is defined by DigIn2 .. 1 (X14.2 and
X14.14) at power up plus the value of 6081h
(MACID Parameter Value) as offset. DigIn2 is
the most, DigIn1 the least significant bit. ( 00b =
ID 0, 11b = ID 3 (plus offset))
NTI AG / LinMot User Manual LinRS Interface / 03/10/2017 Page 53/59
