SCP System • System description
CP_SEM_60-00-00.002 11
3 System description
3.1 SCP System
Either a Stöckert/Sorin HLM (S3/SC/S5/C5) or the SCPC system is required to operate or supply the
current for the SCP System. The following pages provide an overview of each of the components.
3.1.1 SCP System components
The SCP System consists of the following components:
◗ Pump control panel ➜ Operation and configuration of the
SCP System
◗ Drive unit ➜ Revolution
®
drive by magnetic coupling
◗ Emergency drive unit ➜ Manual drive unit for Revolution
®
◗ Flow sensor ➜ Measurement of blood flow and detection
of bubbles
