SCP System • Replacing components
CP_SEM_60-00-00.002 31
5.1.2 Replacing pump control panel components
EPROM
Fig. 14: Replacing the EPROM
The EPROM A 38 contains the operating software (firmware) of the SCP System. Replacement is
necessary in the following cases:
◗ To perform an update
◗ In the event of error messages that indicate a defect in the EPROM (E02, E81).
Observe the following instructions when replacing the EPROM:
◗ Always use suitable removal and insertion tools so as not to bend the contacts.
◗ Avoid static charging (and hence damaging the electronic components) by suitable earthing
measures.
◗ When inserting the new EPROM, ensure the correct alignment (notch pointing towards centre of
board).
