SCP System • Appendix
46 CP_SEM_60-00-00.002
6.1.2 Electrical specifications
6.1.3 General data
SCP Pump control panel
Drip-proof IPX2
Input voltage 24 V-supplied via heart-lung machine/
SCPC System
Input current 6 A
Power consumption 120 W max.
SCP Drive unit
Drip-proof IPX2
Input voltage min.: 20 V
DC
nom.: 24 V
DC
max.: 32 V
DC
Pump data
Range of speed 0 through 3500 RPM
Speed accuracy ±10 RPM
Displays
Range of RPM display 0 through 3500 RPM
Resolution of the displayed actual value 1 RPM
Resolution of the adjusted set value 1 RPM
Measurement range: Flow -10 through +10 LPM
Resolution of the 7-segment display of the
flow rates
0.1 LPM
0.01 LPM
< 0 LPM
> 0 LPM
Accuracy of the measured flow ±10% of the actual value
and/or ± 0.1 LPM, whichever is greater
Alarm limits of the displayed flow Flow too high: 0.5 through +10.0 LPM
Flow too low: 0.0 through 5.0 LPM
Retrograde flow: 0.0 through 1.0 LPM
Pressure display
Range of display -99 through +999 mmHg
Resolution 1 mmHg
Accuracy of the measured values ±5 mmHg
Emergency drive unit
Speed display 7 LEDs
Resolution 500 RPM per LED (starting at 1000 RPM)
Displayed range of speed 1000 through 4000 RPM
Accuracy ±250 RPM
