SCP System • Appendix
CP_SEM_60-00-00.002 49
6.5 Service component part numbers
These part numbers refer to parts and components that are used exclusively for service purposes.
6.5.1 Pump control panel
Mod. Item Description Number SP number
A 1 Upper casing 75-521-101
Foil for (A 1) 76-102-941
A 2 Shaft angle encoder, consisting of see page 37
Rotary knob A 43 96-190-057
Mounting nut A 44 28-91-76
Washer PA 6.2 x 12.0 x 0.5 A 45 71-120-514
Guide sleeve A 46 60-02-02
Shaft angle encoder A 47 97-103-603
Threaded rod, M3x3 71-118-301
Washer A 48 60-02-04
A 3 Kit PCB ZBA board with pusher caps
– Display board
– Pusher caps (6 pieces)
ZPA 9908
003-20-0001
A 4 CPU board ZKR 9910 90-305-190
A 5 Flow sensor board DIGIFLOW 90-900-520
A 6 Lower casing 75-521-102
A 7 Mains filter 96-401-012
A 8 Toggle switch 96-121-209
A 9 Connecting cable to E/P pack, S3
Connecting cable to E/P pack, S5
97-102-616
97-102-626
A 10 Holder (complete) for control panel 60-02-13
A 38 EPROM (firmware) ZKR V2.2 93-484-232
A 42 Flow sensor cable 97-101-898
