SCP System • Appendix
50 CP_SEM_60-00-00.002
6.5.2 Drive unit
Mod. Item Description Number SP number
A 9 Connecting cable to E/P pack, S3
Connecting cable to E/P pack, S5
97-102-616
97-102-626
B 5 Motor control board 9909 90-305-185
B 6 Connecting cable to pump control panel 97-102-615
Kit - Splash protection SCP, consisting of 003-20-0002
B 2 – Base plate
– Countersunk head screws (hex head screw),
DIN 7991, M3x8 (4 pieces)
B 3/B 4 – Splash protection with slide bearing
