• The inverter must not be installed near flammable or explosive materials or near the
equipment with strong electromagnetism.
• The inverter is suitable for mounting on concrete or other non-combustible surfaces only.
• The bearing capacity of the wall must be greater than 35kg. Otherwise, the wall may not
be able to prevent the inverter from dropping.
Step 2: Secure the mounting bracket on the wall
• Use expansion bolts or correct wall fixings to attach the
mounting bracket to the wall tightly.
Step 3: Mount the inverter to the mounting bracket
• Carry the inverter by holding the heat sink on two sides and hang the inverter on
the mounting bracket. And then lock the side with screw.
Step 4: Installation Self-check
• Ensure the inverter is well fixed;
• Ensure DC-switch is switched to OFF.
