LNS Alpha ST320 S2 - Page 101

CHAPTER 8: OPERATION 8-23
ALPHA ST320 S2
MODE 20 ：
：：
： Anti-vibration device setup 1 of 3 (refer to MODE 24, 18)
Define how the first front rest action during bar change
process.
0 – The front rest closes when the TOP CUT device activated
by new bar stock (SQ1 + 200mm).
1 – The front rest closes when the bar feed system arrives at
TOP CUT position and sends a START signal.
MODE
20
sens
or
SQ1+200mm
TOP CUT
position
0
1
MODE 21 ：
：：
：
This parameter originally is left blank.
MODE 22 ：
：：
： Lathe type setup 3 of 3 (refer to MODE 21, 22 for related setup)
0 – For the lathes whose brand name are not “EASY”.
1 – For the lathes whose brand name are “EASY” only.
MODE 23 ：
：：
： HMI display language setup
0 – Optional language
OPEN
CLOSED
